The 622 Mbps series are hot pluggable Small-Form-Factor (SFP) duplex, bidirectional and CWDM transceiver modules expressly designed for high speed communication applications that requiring rates of up to 622 Mbps. The transceivers are manufactured with LC receptacle that is compatible with the industry LC connector standard. All SFP transceivers have the digital diagnostic monitor feature.
SFP Transceivers – 622 Mbps
- Hot pluggable Small-Form-Factor (SFP) duplex
- Bidirectional and CWDM transceiver modules
- Rates of up to 622 Mbps
- Digital diagnostic monitor feature
|
|
Unit |
SX |
LX |
HX |
ZX |
UX |
EZX |
|
Average output power (min / max) |
dBm |
-9 / -3 |
-15 / -8 |
-5 / 0 |
-3 / 2 |
0 / 5 |
1 / 6 |
|
Receiver sensitivity |
dBm |
-22 |
-28 |
-28 |
-28 |
-31 |
-34 |
|
Overload |
dBm |
-3 |
-8 |
-8 |
-8 |
-10 |
-10 |
|
Maximum distance |
km |
0.550 |
20 |
40 |
80 |
120 |
160 |
|
Fiber type |
- |
MMF |
SMF |
SMF |
SMF |
SMF |
SMF |
|
Optical link budget |
dBm |
13 |
13 |
23 |
25 |
31 |
35 |
|
Wavelength / laser type |
nm |
850 / VCSEL |
1310 / FP |
1310 / FP 1550 / DFB |
1550 / DFB |
1550 / DFB |
1550 / DFB |
Table 1: Basic technical specifications according to distance.
For high speed communication applications
ACT_31-12_EN-SFP-622M
