The OPTOKON transceivers are compliant with SFF-8432. This upgrade, and reliability benefits by virtue of being hot- pluggable, also is designed for single-mode and multimode fiber with cost effective and high performance. 6.25 Gbps SFP+ can be used for CIPRI (2.456, 4.915, 6.144 Gbps), LTE (4.915, 6.144 Gbps) or OBSAI (6.144 Gbps) applications.
SFP+ Transceivers – 6.25 Gbps
Temperature:
OPTOKON is always trying to satisfy as much market demand as possible and with this in mind, almost all OPTOKON SFP transceivers are manufactured in the Commercial, Extended and Industrial temperature ranges to provide you all possibilities you need for your application.
Safety and regulatory compliance:
| Electrostatic discharge (ESD) Electromagnetic Interference (EMI) Laser Eye Safety Component Recognition ROHS EMC |
IEC/EN 61000-4-2 FCC Part 15 Class B EN 55022 Class B (CISPR 22A) Class 1 laser product IEC/EN 60950, UL 2002/95/EC EN 61000-3 |
|
|
Unit |
SR |
LR02 |
LR |
LR20 |
ER |
ER60 |
ZR |
|
Average output power (min / max) |
dBm |
-6 / -1 |
-6.5 / 0 |
-6.5 / 0 |
-6 / 0 |
-1 / 4 |
0 / 5 |
0 / 5 |
|
Receiver sensitivity |
dBm |
-15 |
-14 |
-14 |
-15 |
-15 |
-20 |
-23 |
|
Overload |
dBm |
-1 |
0 |
0 |
0.5 |
0.5 |
-6 |
-6 |
|
Maximum distance |
km |
0.300 |
2 |
10 |
20 |
40 |
60 |
80 |
|
Fiber type |
- |
MMF |
SMF |
SMF |
SMF |
SMF |
SMF |
SMF |
|
Minimum optical link budget |
dBm |
9 |
7.5 |
7.5 |
9 |
14 |
20 |
23 |
|
Wavelength / laser type |
nm |
VCSEL |
FP |
DFB |
DFB |
DFB |
DFB |
DFB |
Table 1: Basic technical specifications according to distance.
- CIPRI (2.456, 4.915, 6.144 Gbps)
- LTE (4.915, 6.144 Gbps)
- OBSAI (6.144 Gbps)
ACT_13-16_EN-6G-SFP+
