Outdoor Gel-Filled Multitube Cable 12-144F (2.3)

Fully dielectric cable for external installation on cable trays or into duct by pulling, space between the tubes is filled by gel

Fibre Type	G.652.D, G.657.A1, G.657.A2, G.655, OM1, OM2, OM3, OM4, OM5
Fibre colour	Blue, Orange, Green, Brown, Grey, White, Red, Black, Yellow, Violet, Pink, Aqua
Tube colour	Blue, Orange, Green, Brown, Grey, White, Red, Black, Yellow, Violet, Pink, Aqua
Central strength member	FRP rod (coated if necessary)
Core filling compound	Medium-viscosity filling compound
Core wrapping	Polyester foil
Peripheral strength members	Water-swellable glass yarns
Ripcord	1x under outer jacket
Outer jacket material	UV resistant black HDPE
Outer jacket thickness	1.5 mm

Number of fibres	12	24	36	48	60	72	96	144
Number of fibres in tube	12	12	12	12	12	12	12	12
Tube count (layers)	1	2	3	4	5	6	8	12
Filler count	5	4	3	2	1	0	0	0
Nominal outer diameter (mm)	10.6	10.6	10.6	10.6	10.6	10.6	12.0	15.0
Calc. cable weight (kg/km)	93	94	95	95	96	97	123	188
Calc. cable weight (kg/km)	3100	3100	3100	3100	3100	3100	4100	5400	IEC 60794-1-101
Long-term tensile strength (N)	1700	1700	1700	1700	1700	1700	2600	3700	IEC 60794-1-101
Crush resistance (N/100 mm)	2000								IEC 60794-1-103
Max. impact loading (Nm)	20								IEC 60794-1-104
Min. bend radius not load (OD)	15								IEC 60794-1-111
Min. bend radius load (OD)	20								IEC 60794-1-111
Operating temperature range (°C)	-40 to +70								IEC 60794-1-201
Storage temperature range (°C)	-40 to +70								IEC 60794-1-201
Installation temperature range (°C)	-15 to +50								IEC 60794-1-201
Water tightness (1 m / 24 hrs.)	No leakage								IEC 60794-1-205
Class of fire reaction	Fca								EN 50575, EN 13501-6
